4. Print height can be customized, unlimited length.
One Set Of Ink, 5 Colors, Red Yellow Blue Black White; Each Color 500ml;
One Set Of Uv Ink Costs 95usd, Which Can Print 150 Square Meters. So The Average Of Ink Consumption 16.7ml/Sqm. The Cost Is 0.63usd/Sqm.
One Set Of Water Based Ink Costs 75usd, Which Can Print 150 Square Meters. So The Cost Is 0.5usd/Sqm.
4720 lifespan is about 40,000 square.
360x720dpi/720x1080dpi/720x1440dpi/
1080x1440dpi/1440x2880dpi
Equipped with ink curing lights for uv model, no restrictions on any material quality of fine picture, good color, waterproof protection of the sun protection more lasting, no need for waterproof treatment.
| KD260 Parameters | ||||
| Printing software | Genuine professional printing software | |||
| Using ink | Special environmental protection organic water-based ink (waterproof, anti stripping) | |||
| Control mode | Wired / wireless printing | |||
| Transportation | (foldable) | |||
| Power consumption | No load 20W, maximum 250w | |||
| Surface tracking | Hyperbolic banner sensor, up and down bidirectional induction | |||
| Ink supply system | Positive pressure system single color single supply, 4-color ink bin one body | |||
| Print size | 2.5Height × width, more than 2 meters can be seamless splicing | |||
| Construction noise | Standby < 20db, drawing < 70db | |||
| Supporting pictures | Photos taken by mobile phone / camera and Internet | |||
| Power requirements | Household electricity: 220 VAC or 380 VAC | |||
| Applicable media | White wall, ceramic tile, glass, metal, acrylic, paper, etc | |||
| Format of national film | include PSD.CDR, JPG, JPEG, PNG, BMP, tiff, EPS, AI and PDF | |||
| Color drawing technology | Micro piezoelectricity spray technology, variable ink drop, high tolerance error emerging technology, automatic memory recoverytechnology for construction interruption | |||
| Print Resolution | 360x720dpi/720x1080dpi/720x1440dpi/1080x1440dpi/1440x2880dpi | |||
| Operating environment | -20 ° c-50 ° C (- 4f-122f), 10% - 70% relative humidity, non condensing state | |||
| Storage environment | -21c-5o ° C (- 22f-140 ° f), 10% - 70% relative humidity, non condensing state | |||
| operating platform | Windows xP/7/8/9/10 | |||
| Certification qualification | Green environmental protection certification, national standard test qualified (GB 18582-2001, gbt9756-2001), CE certification | |||
| Printing speed | PASS | M2 / h (M '/ h) | ||
| Fast mode | A | 15 | ||
| Production mode | B | 10 | ||
| Quality model | C | 7 | ||
| HD mode | D | 5 | ||
| External dimension | Machine scale mm); length 700* width 300* height 2600 | Package size (mm): length 800*width 460*height 2700 | ||
| Machine weight | Machine 60kg (fuselage 30kg + 3 guide rails 30kg) | Gross weight 115KG in wooden case | ||
| Key Components | ||||
| Nozzle specification | Epson 10 generation high precision printing nozzle 2 | Electric machinery | 3 Imported intelligent servo motor + reducer | |
| main board | 8Core high speed CPU, 4GB memory, high speed USB 1o | Wall detection | 2Nano distance detectors | |
| level | Imported precision level | Power failure alarm | Real time power failure alarm system | |
| UPS power supply | Super uninterruptible power supply with 3 hours of power failure | Laser positioningLaser positioning | Precise infrared laser positioning system | |
| Shaft guide | High strength precision railway track, 4 sections, 1.5m, 6m in total | Shaft guide | Imported linear drive module | |
| Ink supply technology | Positive pressure system ink supply, need to draw ink | Gift Gallery | Free 2T Library | |
| Language | Chinese / English (other languages can be customized) | |||
| Note: the above parameters are design parameters. In case of any difference, the actual use efficiency of the equipment shall prevail. | ||||
